Plastic Bottle Carbonated Beverage Filling Machine For Beverage Production Line

Jumpfruits adheres to the market-oriented, technology-leading, quality-oriented, service-guaranteed, establishment of a sound quality assurance system, and equipped with complete testing and inspection facilities, we have a high-quality technical development and manufacturing workforce , with rich experience in design and manufacturing.

We wholeheartedly provide all kinds of carbonated beverages, pure water, mineral water, fruit juice, soy milk, wine and other edible liquids in bottles, cans, cups, barrels, hot filling complete sets of equipment and drinking water to new and old customers at home and abroad , mineral water, purified water and other water treatment equipment. Among them, RCGF series, CGF series, DCGF series bottled and QGF bottled beverage production lines, and QHS series beverage mixers are all manufactured by digesting and absorbing advanced technologies from Germany, Italy and Japan, and they have reached the international advanced level in the 1990s. At the same time, our unit can provide customers with technology
Consulting, workshop graphic design, installation and commissioning, technical training and other supporting services. At present, the company’s products sell well in 29 provinces, municipalities and autonomous regions across the country, and are exported to more than 20 countries and regions such as Southeast Asia, Russia, Uzbekistan, West Asia, and Africa.

Technological Process: air feeding bottle – automatic internal and external rinsing → filling → capping

Machine Parameters

Number of stations: 8 for bottle washing, 8 for filling, 4 for capping
Rated production capacity: 1500-1800 bottles/hour (500ml)
Filling method: isobaric filling
Suitable for bottle type: Ø30-96mm, bottle height 100-310mm
Air source pressure: 0.7Mpa
Gas consumption: 1 cubic meter per second
Bottle washing water pressure: 0.2-0.25Mpa
Bottle washing water consumption: 0.2 tons/hour
Rated voltage: 380V
Total power: 2.2KW
Appliances: Schneider
Material: 304 stainless steel
Pipe: 304 stainless steel pipe
Dimensions of the host: 1900*1300*2200mm (length*width*height)
Equipment weight: 1500KG
