China Paper Tube Labeling Machine For Composite Can factory and manufacturers

Paper Tube Labeling Machine For Composite Can

Short Description:

Send email to us Download as PDF

Product Detail

Product Tags

Overview

Quick Details

Type:: LABELING MACHINE

Packaging Material:: wood, can labeler machine

Packaging Type:: Bags

Application:: Beverage, Food, MEDICAL, Commodity, Chemical, Machinery & Hardware, APPAREL, Textiles, can labeler machine

Applicable Industries:: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, can labeler machine

After Warranty Service:: Video technical support, Online support, Spare parts, Field maintenance and repair service

Local Service Location:: None

Showroom Location:: None

Condition:: New

Automatic Grade:: Automatic

Driven Type:: Electric

Voltage:: 220V/50HZ

Place of Origin:: Shanghai, China

Brand Name:: JUMPFRUITS

Dimension(L*W*H):: 2000(L)*950(W)*1260(H) (mm)

Weight:: 200kg

Certification:: ISO

After-sales Service Provided:: Field installation, commissioning and training, Overseas service center available

Warranty:: 1 Year

Key Selling Points:: Easy to Operate

Marketing Type:: New Product 2020

Machinery Test Report:: Provided

Video outgoing-inspection:: Provided

Warranty of core components:: 3 months

Core Components:: PLC, Pressure vessel, Gear, Motor, Engine, Bearing, Gearbox, Pump, can labeler machine

Product name:: can labeler machine

Bottle type:: Round Square Flat Pet Bottle

Other name:: automatic labeling machine

Function:: Auto Sticker Labeling Equipment

Model:: JPF-TB4586

Labeling speed:: 20-200pcs/min

Advantage:: Economy Labeling Machine

Material:: Stainless Steel

Name:: Labeling Machine

Supply Ability

Supply Ability:: 15 Set/Sets per Month

Packaging & Delivery

Packaging Details: package in cartonscan labeler machine

Port: shanghai

Lead Time :

Quantity(Sets)	1 – 1	>1
Est. Time(days)	65	To be negotiated

Product Description

1, Performance features:
1. The machine is suitable for labeling cans. After the can is rolled into the machine, it is driven to roll by the belt pressed on the can. When the can passes through the heat
At the glue melting station, the cans are coated with hot-melt glue. As the cans move forward, the glue on the cans is pressed to the front of the label,
The label was glued up and began to roll on the can. At the same time, the gluing mechanism at the end of the label also applies glue to the end of the label.
As the can moved on, the label was rolled onto the can. Then the belt is rolled and driven out of the machine.
2. The machine has an alternate supply mechanism, so it does not need to stop when adding the standard.
3. The glue supply at the end is controlled by the can, with glue supplied by can, but not without can.
4. The machine adopts frequency conversion speed regulation, which can be adjusted at any time according to the production needs.
5. The machine is simple to replace the tank type, less replacement parts, only glue at both ends of the label, the amount of glue used is small, and the cost of labeling is low.
2, Suitable range:
1. This machine is a tin can labeling machine, which is suitable for tin can labeling;
2. It can quickly change the size of tinplate can, and the operation is simple, neat, beautiful and clean.
3, Technical parameters:
Labeling capacity: 200-500 cans / min (varies with can size)
Suitable can size: diameter: Φ 40-120mm, height: 250mm
Label size: width: 23-254mm; length: 117-380mm
Label adhesive: hot melt adhesive + quick drying adhesive
Power supply: three phase; 380V (or customized as required)
Electric power: 3kw
Compressed air: 2-4kg / m2; 10 L / min
Overall dimension: length 1856mm × width 750mm × height 1250mm
Weight: 750KG
