Non-fried Vacuum Freeze Pineapple / Lemon / Banana / Durian Dryer

Short Description:


Product Detail

Product Tags

Overview
Quick Details
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
JUMPFRUITS
Model Number:
LG-20
Type:
Dryer
Voltage:
380V
Power:
96kw
Weight:
10T
Dimension(L*W*H):
1200*1500*15mm
Certification:
CE ISO
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Product name:
Non-fried vacuum freeze pineapple / lemon / banana / durian dryer
Material:
Food Grade Stainless Steel
Function:
Non-fried vacuum freeze dryer
Capacity:
200kg/n
Usage:
Freeze Drying Fruits
Item:
retaining 100% nutrition of pineapple
Supply Ability:
5 Set/Sets per Month industrial freeze dryer
Packaging & Delivery
Packaging Details
Wooden case in 40GP
Port
Shanghai
Lead Time :
30days after received the deposit
Product Description

Non-fried vacuum freeze pineapple / lemon / banana / durian dryer

Main features of food type vacuum freeze dryer:

● Pre-freezing and drying the split structure at the same time, improving the freeze-drying efficiency and shortening the freeze-drying time.

● Space-grade aluminum alloy separator material, double-sided radiant heating, emissivity of more than 90%, good temperature uniformity.

● High-efficiency mixed refrigerant medium, low freezing point and high boiling point, high heat exchange efficiency and long service life.

● Drying curve optimization control algorithm, which can control the heating rate and vacuum value of the product during the drying stage.

● The ed gas guiding design and control technology has strong water-capacity and high drying efficiency.

● The pallet is stamped and formed by aviation anti-rust aluminum alloy, and has a high heat absorption rate through special surface treatment. Each drying compartment is equipped with 2 holding trays.

● Industrial-grade embedded touch screen + dedicated SH-HPSC-III modular controller, the system is stable and reliable, and the control precision is high.

● The professionally designed FD-MANAGER control system can save multiple sets of process recipes, and can adjust the process in real time during the drying process to improve the process optimization rate.

● Flexible manual + automatic control mode, manually used for groping process, automatically used for batch production.

● Accurate sensor calibration to ensure the accuracy of long-term use of process parameters.

● User level and password can be set, and operation management can be decentralized.

● Optional powerful LYO-MEGA PC control system can record and save operating data, curves and alarm records for up to ten years, improve product traceability; at the same time facilitate observation, operation and fault diagnosis.

● Can be customized according to user needs.

Vacuum Freeze dryer
Style NO.
LG-20
LG-50
LG-100
Shelf area (㎡)
20.6
52.92
105.84
Shelf quantity (layer)
8+1
9+1
18-1
Shelf size (mm)
1200*2150*15
4900*1200*15
4900*1200*15
Shelf spacing (mm)
80
80
80
Number of vehicles (set)
2
3
3
Shelf temperature range (℃)
-120
Maximum freezing capacity (kg)
400
1000
2000
Condensing temperature(℃)
-50
Cooling mode
water cooling
Defrosting mode
Spray immersion
ultimate vacuum (Pa)
10
Power (kw)
96
150
230
Cooling water (m³/h)
40
80
160
Air compression (m³/min)
30
Dimension(m) L*W*H
Drying bin:3.7*2.2*2.5

Freezer:3.3*2.0*2.7
Unit: 3.7*2.0*2.2
Drying bin:6.8*2.2*2.5

Freezer:6.5*2.0*2.7
Unit: 6.8*2.0*2.2
Drying bin:7*2.2*2.5

Freezer:6.5*2.0*2.7
Unit: 3*2.0*2.2
Weight(T)
10
29
46
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory,pickup service.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
