Aseptic big bag filling machine is widely used in aseptic packaging of liquid food such as juice, fruit pulp and jam. At room temperature, the product can be stored for more than one year, which can save the cost and risk of low-temperature refrigerated transportation.

The aseptic big bag filling machine is directly connected to the sterilization machine, and the products after UHT sterilization can be directly filled in aseptic bags. Aseptic bags are aluminum-plastic composite multi-layer bags, which can effectively isolate sunlight and oxygen, and maximize product quality.
The temperature adjustment system automatically adjusts the temperature of the filling chamber, and uses the steam injection method to sterilize the bag mouth and the filling chamber.
The aseptic filling machine can fill various kinds of aseptic bags or aseptic packaging boxes from 1L to 1300L.

Equipment performance and technical indicators of aseptic big bag filling machine:
1. Provide a variety of security measures (position control, metering control, temperature control) to prevent mechanical damage and ensure product quality;
2. Adopt mass weighing system control to realize quantitative filling and more accurate filling;
3. Mirror welding technology is adopted to ensure that the welding seam is smooth and flat, leaving no hygienic dead corners;
4. The product valve and the moving parts of the filling head are protected by steam barrier, and the filling room is sterilized by steam;
5. The programmable controller is used to realize the automatic operation of the equipment.

Types of Aseptic Big Bag Filling Machines:
At present, the main types of sterilization filling machines in the market are: casing-type aseptic filling machines and plate-changing aseptic filling machines used in the food industry such as fruit juice, jam, pulp, milk, etc.; there are more large-scale aseptic filling machines. Yes, the product with better quality is the flash aseptic filling (FlashCooler), which uses the direct injection of steam into the product-type aseptic filling machine. Instantaneous sterilization can more fully ensure the color, appearance and taste of the product. It is used in the milk and orange juice industry with relatively large production volume and the tomato paste industry that requires a particularly large amount of processing; in the production of small can packaging industry, there is also a reaction gold type aseptic filling machine.
