Complete Set Beer Brewery Equipment For Your Plant

Short Description:


Product Detail

Product Tags

Overview
Quick Details
Processing:
Fermenting Equipment
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
JUMPFRUITS
Model Number:
JP-BM0012
Processing Types:
Alcohol
Voltage:
380V
Power:
15-70Kw Depends
Dimension(L*W*H):
Capacity Request
Weight:
1-3T
Certification:
ISO
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Material:
Stainless Steel 304
Function:
Brewing Beer Brewing Equipment
Keywords:
Brewery Machine
Capacity:
100-5000L
Heating method:
Steam Heating
Control system:
Pressure Auto Control
Usage:
Protoplasm Beer Production
Packaging Details
wooden case
Port
Shanghai
Lead Time :
30 days after receving the deposit
Product Description

Beer brewing production process

A. Malt process: selection of wheat – dip wheat – germination – drying and coke – de-rooting

B.Saccharification process: comminution of raw materials – saccharification (gelatinization) – wort filtration – wort boiling (with hops) – cooling

C.Fermentation process: fermentation (except yeast) – filter wine

D.Filling process: washing bottle – bottle inspection – filling wine – sterilization – labeling code – packing and storage

ProcessDetailed

1) Selected barley: Yanjing Beer is made of high quality imported Australian wheat and wheat.

2) Soaking wheat: increase the moisture content of barley and remove dust, debris, microorganisms and other harmful substances.

3) Germination: Various enzymes are formed in the wheat grains, and some high molecular substances such as starch, protein, and hemicellulose are decomposed to meet the needs of saccharification.

4) Drying and coking: remove the moisture in the malt, prevent the spoilage of the malt, and facilitate the storage. At the same time, the malt smell of the malt is removed, the color, the aroma and the taste of the malt are generated, and the growth of the green malt and the decomposition of the enzyme are stopped.

5) De-rooting: Root buds have strong hygroscopicity, easy to absorb water and rot during storage. Root buds have bad bitterness, which will destroy the taste and color of beer, so roots should be removed.

6) Pulverization of raw materials: After the raw materials are pulverized, the specific surface area is increased, and the soluble substances are easily leached, which is beneficial to the action of the enzyme and further decomposes the insoluble substances of the malt.

7) Saccharification: The insoluble polymer substance in the malt and the dressing is decomposed into a soluble low molecular substance by using a hydrolase in the malt.

Gelatinization: The insoluble polymer substances in the malt and malt auxiliary materials are gradually decomposed into soluble low molecular substances by various hydrolyzing enzymes contained in the malt under suitable conditions.

8) Wort filtration: The material in which the onion material is dissolved in the mash is separated from the insoluble wheat grain to obtain a clear wort, and a good extract yield is obtained.

9) Wort boiling: The purpose of boiling is mainly to stabilize the components of wort, which are: enzyme passivation, wort sterilization, protein denaturation and flocculation precipitation, water evaporation, hopping of hop components.

Adding hops: Adding hops is mainly to give the beer a bitter taste, to give the beer a unique aroma, and to improve the abiotic stability of the beer.

10) Cooling: rapid cooling, lowering the temperature of the wort, meeting the requirements for yeast fermentation, and separating and separating the hot and cold coagulum in the wort to improve the fermentation conditions and improve the quality of the beer.

11) Fermentation: The computer strictly controls the temperature and the physiological state of the yeast. The yeast “eats” maltose and metabolizes the process of CO2 and beer flavor.

12) Filter wine: Fermented mature beer, through the separation medium, remove solid suspended matter, residual yeast and protein coagulum to obtain clear and transparent beer.

13) Bottle inspection: The computer uses photoelectric sensing technology to perform laser point detection.

Washing bottles: automatic washing bottles, including soaking, pre-spraying, alkali 1 soaking, alkali 2 soaking, hot water warm water spray, empty line titration, etc.

14) Irrigation: The bottle is controlled by computer, vacuum is applied twice, CO2 is prepared twice, wine is poured, and the lid is pressed.

15) Sterilization: After Baco’s heat sterilization, it kills active yeast. There is no other bacteria. Pure draft beer is not sterilized, so it is purer, cooler and fresher.

16) Labeling: Use the krones advanced equipment to affix the trademark and spray the date of manufacture.

17) Sub-loading the library: The beer is packed into boxes and stored in the warehouse using advanced equipment from krones.

Main products
Our Main business  producs
1
tomato paste / puree / jam / concentrate, ketchup, chilli sauce , other fruit & vegetables sauce / jam processing line
2
Fruit & vegetables ( orange , guava, cirtrus, grape, pinapple, cherry, mango, apricot.etc. ) juice and pulp processing line
3
Pure, mineral water, Mixed beverage, drink (soda, Cola, Sprite, carbonated beverage, no gas fruit drink, herbal blend drink, beer,cider,  fruit wine .etc. ) production line
4
Canned fruit & vegetables ( tomato, cherry, beans, mushuroom, yellow peach, olives, cucumber, pineapple, mango, chili, pickles and so on. ) production line
5
Dried fruit & vegetables ( dried mango, apricot, pineapple, raisin, blueberry .etc. ) production line
6
Dairy (UHT milk, pasteurized milk, cheese, butter, yogurt, milk powder, margarine, ice cream)production line
7
Fruit and vegetable powder (Tomato, pumpkin, cassava powder, strawberry powder, blueberry powder, bean powder, etc. ) production line
8
Leisure snack (Dried freeze-dried fruit, puffed food, french fried potato chips, etc. ) production line
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory,pickup service.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
