Hot Sale Automatic Filling Machine Automatic Multihead Double Single Head Tomato and Fruit Aseptic BIB Barrel Bulk Bag Filler

Product Description

 Aseptic Filling System

The aseptic filling system is manufactured by Italian technology and conforms to European design standards. It is an efficient and reliable aseptic packaging equipment for high and low acid foods. It is widely used in aseptic packaging of tomato paste, jam, fruit juice, concentrated fruit juice, vegetable juice, thick pulp, raw pulp, concentrated fruit juice, sauce, soup and dairy products. Fruit juice or pulp can be stored at room temperature for more than one year, and concentrated fruit juice or pulp can be stored at room temperature for more than two years.

Equipment Description & Characteristics

Aseptic filling machines are often used together with sterilizers: Materials sterilized by sterilizers are filled into aseptic bags through aseptic filling machines. The product will not be exposed to the air during production and will be filled into a sterile bag in a filling chamber protected by steam. Therefore, the whole production process will be carried out in a closed and safe sterile system.

1. The main structure is made of high-quality 304 stainless steel;

2. Integrate Italian technology and comply with European design standards;

3. Equipped with flowmeter (mass flowmeter or electromagnetic flowmeter) or electric weighing system (depending on the material and volume of sterile bag);

4. Provide a variety of safety measures (position control, metering control and temperature control) to ensure product quality;

5. Mirror welding technology is adopted to ensure that the welding line is neat and flat;

6. Independent Siemens control system. PLC control and man-machine interface operation (English / Chinese);

7. Movable valve, filling head and other moving parts are protected by steam baffle;

8. Use steam as a protective barrier to keep the filling room sterile all the time;

9. It is matched with the sterilizer and has CIP cleaning and sip online sterilization functions;

10. The filling volume can be adjusted by one key switching according to the volume and size of the sterile bag. Simple replacement of parts and convenient adjustment;

The Control System Adheres to Easyreal’s Design Philosophy:

1. High degree of automation, minimize the number of operators on the production line.
2. All electrical components are international first-class top brands, to ensure the stability and reliability of equipment
operation;
3. In the process of production, man-machine interface operation is adopted. The operation and state of the equipment are
completed and displayed on the touch screen.
4. The equipment adopts linkage control to automatically and intelligently respond to possible emergencies;

eter	Single head single barrel aseptic filling machine	Double head single barrel Aseptic filling machine	Double head (rotating four barrels, ton box) Aseptic filling machine	Single head Bib box middle bag Aseptic filling machine	Double head Bib box middle bag Aseptic filling machine
Model	AF1S	AF2D	AF3D	AF5S	AF6D
Capacity: T/h	1-5	5-10	5-12	1-1.5	1.5-3
Power:kw	1	1	1	1	1
Consumption of steam: kg/h	0.4-0.8Mpa ≈50	0.4-0.8Mpa ≈100	0.4-0.8Mpa 100	0.4-0.8Mpa ≈50	0.4-0.8Mpa ≈100
Consumption of air: M3/min	0.6-0.8Mpa ≈0.04	0.6-0.8Mpa ≈0.06	0.6-0.8Mpa, 0.06	0.6-0.8Mpa ≈0.04	0.6-0.8Mpa ≈0.06
Size of aseptic bags:L	220L	220L	220L,1000L	3-25L	3-25L
Size of bag mouth	1″
Metering method	flow meter or electric weighing sensor			flow meter
Metering error	electric weighing sensor: ±1%, flow meter: ±0.5%
Dimension:mm	1700×2000×2800	3300×2200×3000	4400×2700×3500	1700×1200×2800	1700×1700×2800
