2021 Automatic Tunnel Spray Sterilizing Machine / Bottle Washer And Sterilizer

Short Description:


Product Detail

Product Tags

Overview
Quick Details
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
JUMPFRUITS
Model Number:
JPML-1124
Type:
bottle sterilizing machine
Voltage:
220V/380V
Power:
2.2kw
Weight:
2T
Dimension(L*W*H):
1380*1200*2000mm
Certification:
CE ISO
Year:
2019
Warranty:
1 Year
After-sales Service Provided:
Field installation, commissioning and training
Production capacity:
500kg-5T/H
Material:
SUS304
Usage:
sterlizing glass jars
Name:
sterilizing bottle
Capacity:
2000b/h
Feature:
High Capacity
Color:
Silver
Application:
cans, glass bottles
Supply Ability
Supply Ability:
10 Set/Sets per Month post sterilizing machine for jars
Packaging & Delivery
Packaging Details
1.Stable wooden package protects machine from strike and damage. 2.Wound plastic film keeps machine out of damp and corrosion.3.Fumigation-free package helps the smooth customs clearance.4.The big size machine will be fixed in container without package.
Port
shanghai port
Lead Time :
Quantity(Sets) 1 – 1 >1
Est. Time(days) 60 To be negotiated
Product Description

Continuous spraying pasteurizer Tunnel spray sterilizing machine

Techncal:
Continuous spraying pasteurizer is designed and made on the basis of absorbing and digesting abroad machine. It adopts warm water to preheat,sterilize with recycling hot water, recycling warm water to pre-cool, and cooling water to cool ; it is with the advantages of sterilizing temperature automatic control, and adjustable sterilizing time ; and can be widely used in sterilizing and cooling of juice and beverage in various bottles and cans,electrolyte beverage, wine and condiments. It can be designed and made to the sterilization conditions and production provided by the customer.

Model
JPFGS-001
JPFGS-002
JPFGS-003
JPFGS-004
Production Capacity
1500
2000
Material Inlet Temperature(℃)
25℃-40℃
25℃-40℃
25℃-40℃
25℃-40℃
Warm Keeping Tiime(s)
120-180
120-180
120-180
120-180
Sterilizing Temperature(℃)
92-121
95-121
95-121
95-121
Material Outlet Temperature(℃)
25℃-35℃
25℃-35℃
25℃-35℃
25℃-35℃
Material Inlet Temperature(℃)
30℃
30℃
30℃
30℃
Steam Pressure(Mpa)
0.5Mpa
0.5Mpa
0.5Mpa
0.5Mpa
Steam Consumption(Kg/H)
≈150Kg/h
≈210kG/h
≈280kG/h
≈350kG/h
Compressed Air pressure(Mpa)
0.6Mpa
0.6Mpa
0.6Mpa
0.6Mpa
Compressed Air Consumption (L/H)
50L/H
50L/H
60L/H
60L/H
Final Products
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory,pickup service.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
